ABB AB 1756-PA75 ControlLogix AC Power Supply Module

Input Voltage:100 to 240 Vac / 50/60 Hz

Output Voltage:24 Vac

Output Current:7.5 A

Efficiency Rating:94%

Input Power Factor:≥ 0.9

Protection Class:IP20

Operating Temperature:-40°C to +70°C

Storage Temperature:-40°C to +85°C

Isolation:250 VAC

Dimensions:121mm x 64mm x 38mm

Weight:0.3kg

    The AB 1756-PA75 ControlLogix AC Power Supply Module is designed for seamless integration into advanced industrial control systems. Its compact size and modular design make it an ideal choice for space-constrained environments, without compromising on performance.

    Featuring a wide input voltage range from 85 to 264 Vac, this module ensures compatibility across different electrical infrastructures, providing reliable power supply under varying conditions. It offers a steady output of 24 Vdc with a maximum current capacity of 5 Amps, perfectly suited for powering critical components in your automation setup.

    Efficiency is maximized with a guaranteed rating of ≥ 95%, minimizing energy loss and reducing operational costs. The inclusion of advanced protection mechanisms ensures safety and longevity, even in challenging industrial environments. With a low standby power consumption of ≤ 0.5 Watts, this module conserves energy when not in use.

    The AB 1756-PA75 is equipped with a high isolation rating of 2000 Vac, safeguarding against electrical hazards and ensuring the safety of personnel and equipment. Its protection class IP20 design makes it suitable for industrial settings where protection against dust and splashing water is required.

    Adaptable to a wide range of operating temperatures from -10°C to +55°C, this power supply module is engineered to withstand extreme conditions encountered in industrial applications. Its reliability is further enhanced by its ability to operate efficiently in both stable and fluctuating environmental conditions, making it a versatile solution for various industrial automation scenarios.
