Capacity:7 Slot
Mounting:Panel
Temperature Rating:0 – 60 DEG C
Enclosure Type:Open Type
Form Factor:Slot Type Chassis
Cooling Method:Convection
Length:5.8 IN
Width:11.3 IN
Height:6.8 IN
Maximum Backplane Current:5.1 VDC at 10 A, 24 VDC @ 2.88 A
Weight:2.4 LB without Modules
Power Rating:Power consumption: 1.8 W, Power Dissipation: 6.1 BTU/HR
Engineered for efficiency and reliability, the AllenBradley AB 1746-A7 SLC 500 Chassis offers a versatile platform for industrial automation applications. With its seven slot design, this chassis provides ample space for expansion, allowing for customized control systems tailored to specific operational needs.
Designed for robust performance within a wide range of environmental conditions, from 0 to 60 degrees Celsius, the open type enclosure ensures protection against dust and debris while maintaining optimal airflow for efficient cooling through convection.
Featuring an impressive 5.1 VDC at 10 A and 24 VDC at 2.88 A maximum backplane current capacity, this chassis ensures reliable power distribution to attached modules, supporting high-performance operations without compromise.
At just 2.4 pounds when not loaded with modules, the lightweight design facilitates easy installation and maintenance on the panel, enhancing workspace flexibility and accessibility.
Backed by comprehensive standard approvals including KC certification, GOST, and marine specifications, this chassis is suitable for a wide array of industrial environments, ensuring compatibility and safety across various sectors.
