Input Supply Voltage Rating:120 / 240 VAC, 1-Phase, 50-60 Hz
Continuous Output Current:5.7 Amperes
Number of Inputs:12 configurable inputs
Transmission Rate:10/100 Mbps ethernet interface
Distance:Maximum 100 m per ethernet I/P segment
Safe-Torque Off (STO) Functionality:Certified for use up to ISO 13849-1 performance level d (PLd) safety category 3
Operational Temperature Range:0 to 40 °C (32 to 104 deg. F)
Relative Humidity Range:5 to 95% non-condensing
Maximum Installation Height:1500m (4921ft) without de-rating
Weight:1.5 Kg (3.3lb)
Dimensions:238mm x 185mm x 68.0mm (9.3in x 7.29in x 2.68in)
The Allen-Bradley 2097-V31PR2 AC Drive is equipped with four (4) inputs per group, each with a dedicated common terminal, providing flexibility and ease of connection to various control systems. This modular design ensures compatibility and simplifies the integration process.
Equipped with a robust Ethernet interface, the drive supports motion over Ethernet, enabling efficient data transfer and control synchronization with other components in the system. It is certified for use in safety-critical applications, ensuring reliability and peace of mind in hazardous environments.
The 2097-V31PR2 supports Safe-Torque Off (STO) functionality, which is crucial for maintaining safety standards in industrial machinery. It meets ISO 13849-1 performance level d (PLd) requirements, ensuring compliance with international safety guidelines.
Featuring twelve (12) configurable inputs, users can easily adapt the drive to their specific needs. These inputs can be configured for a variety of functions, such as travel limit switches, push buttons, manual switches, and proximity sensors, enhancing the versatility of the device.
With an operational temperature range of 0 to 40 °C and a humidity range of 5 to 95% non-condensing, the 2097-V31PR2 is designed to withstand harsh industrial conditions. Its compact size and lightweight construction make it easy to install and maintain in diverse environments.
