Type:High-Resolution Analog Combination
Model Number:1746-NIO4V
Channels:2 Input, 2 Output
Common Mode Voltage Range:-20 To 20 V
Absolute Input Voltage:Plus/Minus 7.5 VDC or 7.5 VAC RMS (Max.)
Input Range:-10 To 10 VDC – 1 LSB
Absolute Input Current:-30 To 30 MA (Max.)
Output Range:-10 To 10 V – 1 LSB
Full Scale:10 VDC
Overvoltage Protection:7.5 VAC RMS
Current Rating:Backplane Current Draw: 55 MA
The AllenBradley AB 1746-NIO4V module is designed to offer unparalleled precision and reliability in industrial automation environments. Its dual-channel design ensures seamless integration of both analog input and output signals, enhancing system responsiveness and accuracy.
Featuring a common mode voltage range of -20 to 20 V, the module is robust enough to withstand a wide variety of industrial conditions, ensuring stable operation even under fluctuating environmental factors.
With an input current capability of -30 to 30 MA and a backplane current draw of 55 MA, this module is optimized for efficient power management and minimal energy consumption, making it suitable for both large-scale and resource-conscious applications.
The AllenBradley AB 1746-NIO4V stands out for its exceptional overvoltage protection mechanism, safeguarding critical systems against transient voltage spikes that could otherwise compromise system integrity.
This module is compatible with a broad spectrum of Allen-Bradley PLCs, offering seamless integration and compatibility, thus simplifying system architecture and enhancing operational efficiency.
