Product Type:Adapter Module
Communication Protocol:ControlNet
Media Type:Dual
Supply Voltage:24V DC
Input Voltage Range:19.2 to 31.2 VDC
Isolation Voltage:850 VDC
Mounting Options:[“DIN Rail”,”Panel”]
Temperature Rating:-20 to 70 DEG C
Power Consumption:7.6 W at 19.2 VDC
Enclosure Type:Open
Environmental Conditions:5 – 95% non-condensing relative humidity
Shock Resistance:30 G operating
Vibration Resistance:5 G at 10 – 500 HZ
Compliance Standards:UL listed
The Allen-Bradley AB 1794-ACN15/C Adapter Module is designed for high-performance integration, enabling efficient communication between ControlLogix PLCs and ControlNet networks. Its robust dual media capability supports flexible installation options, enhancing system reliability.
Equipped with an open type IP20 enclosure, this module ensures a compact footprint suitable for various industrial environments. It offers isolation voltage up to 850V DC, safeguarding against electrical disturbances and protecting the system integrity.
With its 24V DC power supply, the module ensures stable operation under a wide range of environmental conditions, from -20°C to 70°C, making it ideal for applications in harsh industrial settings.
The 400mA load capacity allows for versatile use in various control scenarios, supporting a broad spectrum of input/output operations. The ability to communicate at speeds of 125/250/500 Kbps optimizes data transfer efficiency, ensuring real-time monitoring and control.
For detailed technical specifications or customization requirements, please refer to the Allen-Bradley product manual or contact our technical support team. We are dedicated to providing expert advice and solutions tailored to meet your specific industrial automation needs.
