HITACHI LPF200A Low Pass Filter Board for Shortwave Power Amplifiers – RF & Microwave Solutions

In stock

The HITACHI LPF200A is a specialized low pass filter board designed for shortwave power amplifiers in radio systems, ensuring optimal signal quality and efficient noise reduction.

SKU: 651269
Phone: +86 19066591275
Email: abbdcs36@gmail.com
connect:Linda
Image 2

Material:High-grade FR4 epoxy resin substrate

Operating Frequency Range:1 MHz to 30 MHz

Passband Ripple:≤0.1 dB

Stopband Attenuation:≥40 dB

Impedance:50 Ohms

Size:100mm x 60mm x 3mm

Operating Temperature Range:-40°C to +85°C

Power Handling Capacity:200W peak

Connectivity:2 x SMA connectors

Certifications:CE, FCC, RoHS compliant

    The HITACHI LPF200A is meticulously crafted for applications requiring stringent signal purity, making it an indispensable component in shortwave radio communication systems. Its robust design withstands the harshest environmental conditions, ensuring uninterrupted service in challenging environments.

    Featuring a high-quality FR4 epoxy resin substrate, this filter board offers exceptional mechanical strength and thermal stability, guaranteeing longevity and reliability over extended periods of use.

    With its wide operating frequency range from 1 MHz to 30 MHz, the LPF200A seamlessly integrates into various shortwave communication setups, providing critical filtering capabilities essential for maintaining clear and undistorted signals.

    The combination of a low passband ripple and high stopband attenuation ensures that only the desired frequencies are passed through, effectively reducing noise and interference, thus maximizing the overall system performance.

    Designed for easy integration into existing radio systems, the LPF200A supports dual SMA connectors, facilitating straightforward installation and connection to power amplifiers. Its comprehensive set of features, including CE, FCC, and RoHS compliance, ensures global compatibility and regulatory adherence.

HITACHI LPF200A Low Pass Filter Board for Shortwave Power Amplifiers Radio
