Type Designation:ASCII
Product ID:MVI69E-MBTCP
Communication Parameters:Baud Rate: 110 to 115K baud, Stop Bits: 1 or 2, Data size: 7 or 8 Bits, Parity: None, Even, Odd, RTS Timing delays: O to 65535 milliseconds
Floating Point Data Support:Floating point data movement supported, including configurable support for Enron, Daniel®, and other implementations
Product Model:MVI69E-MBTCP
Compatible Processors:CompactLogix processors with 1769 I/O bus capability version 16 and greater (MicroLogix 1500 not supported)
UDT Creation:Add-on Instruction creates UDTs, providing logical definitions for I/O, status, and control data
RSLogix 5000 Integration:Add-on Profile support for RSLogix 5000 v.20 and greater, improving integration in the CompactLogix system
Diagnostic Data:Diagnostic data available in RSLogix 5000 controller tags, enabling decisions to be made based upon node health
Experience unparalleled network connectivity with the Prosoft MVI69E-MBTCP Communication Module. This module is engineered for maximum efficiency and reliability in industrial automation environments, ensuring smooth operation and seamless data exchange.
Equipped with advanced communication parameters, this module supports a wide range of baud rates and data sizes, offering flexibility and compatibility across various systems. Its versatile RTS timing delays ensure reliable signal transmission under diverse operational conditions.
Designed with the latest in diagnostic capabilities, the MVI69E-MBTCP allows users to make informed decisions based on real-time node health information, directly accessible through RSLogix 5000 controller tags. This feature significantly enhances system monitoring and troubleshooting processes.
The add-on instruction for creating User Datagram Types (UDTs) simplifies data management by logically defining input/output, status, and control data, making it easier for engineers to develop and maintain complex applications.
This module is specifically tailored for use with CompactLogix processors, offering compatibility with version 16 and above, thereby maximizing its utility within the industry-standard architecture. It seamlessly integrates with RSLogix 5000 software, enhancing system interoperability and performance.
