Operating Voltage:3500V DC
Maximum Current:1250A DC
Insulation Class:Class H (180°C)
Switching Frequency:up to 5 kHz
Package Size:125mm x 80mm x 30mm
Cooling Method:Thermal Pad & Heat Sink
Environmental Temperature Range:-40°C to +150°C
Electrical Rating:Continuous Current: 1250A, Peak Current: 2500A
Di/dt & dv/dt Limit:50kA/μs & 12kV/μs respectively
The Siemens A5E00297621 IGBT Module is a critical component in high-power industrial control systems, delivering unparalleled reliability and efficiency.
Featuring a robust design and high insulation class, this module ensures safe operation under extreme environmental conditions, making it ideal for applications requiring exceptional durability.
With a switching frequency of up to 5 kHz, the A5E00297621 enables rapid power conversion, enhancing the responsiveness and overall performance of your system.
Engineered with advanced cooling solutions, including thermal pads and heat sinks, this IGBT module efficiently manages heat, ensuring consistent operation without degradation over time.
Adaptable to a wide range of temperatures from -40°C to +150°C, this module is suitable for various industrial environments, ensuring reliability across different operating conditions.
