Manufacturer:SIEMENS
Model:RMS-TSIG-TZ
Module Category:Time Synchronization
Communication Protocol:IEEE 1588 Precision Time Protocol (PTP)
Accuracy:±100 nanoseconds
Power Supply:24V DC ±10%
Operating Temperature Range:-40°C to +85°C
Storage Temperature Range:-40°C to +85°C
Humidity Range:5% to 95% non-condensing
Dimensions:100mm x 80mm x 50mm
Weight:0.5kg
The Siemens RMS-TSIG-TZ Time Synchronization Module is an essential component for any industrial control system requiring high precision time synchronization. Its advanced technology ensures that all connected devices are synchronized to the same time base, which is crucial for maintaining accurate data collection and process control.
Designed with robust engineering, the RMS-TSIG-TZ module offers a wide operating temperature range from -40°C to +70°C, making it suitable for harsh industrial environments. It supports Ethernet and RS485 communication interfaces, providing flexibility in network integration.
The module achieves synchronization accuracy up to ±1 μs, ensuring that even the most time-sensitive applications can operate seamlessly. With a compact design measuring 100 mm x 100 mm x 50 mm, the RMS-TSIG-TZ fits easily into existing control cabinets without requiring additional space.
Installation is straightforward, with clear instructions provided in the user manual. The module’s power supply operates within a broad voltage range of 24 V DC ±10%, making it compatible with a variety of power sources commonly found in industrial settings.
For added reliability, the RMS-TSIG-TZ includes built-in diagnostics and error correction capabilities. Regular firmware updates are available via the Siemens website, ensuring that your module remains up-to-date with the latest performance improvements and security enhancements.
