Tamagawa TS5214N500 Smartsyn Resolver

Resolution:500 PPR (Positions Per Revolution)

Accuracy:+/- 0.05% of reading + 0.01 degree

Operating Temperature Range:-20°C to +85°C

Enclosure Type:IP67 Rated Dustproof and Waterproof

Operating Voltage:DC 12V to 30V

Load Capacity:Up to 1A

Output Type:4-20mA Analog Current Output

    The Tamagawa TS5214N500 SmartSyn Resolver is engineered with state-of-the-art technology to provide unparalleled precision in angle measurements for industrial automation and control applications. This resolver is specifically designed to withstand harsh environments, ensuring reliable performance under extreme temperatures and moisture conditions.

    Equipped with a resolution of 500 Positions Per Revolution (PPR), it offers exceptional accuracy, critical for applications requiring fine control and high sensitivity. The resolver’s accuracy is guaranteed within +/- 0.05% of the reading, plus an additional 0.01 degree, ensuring dependable and consistent results.

    Featuring an IP67-rated enclosure, this device is completely dustproof and waterproof, making it ideal for use in industries where equipment is exposed to dust, dirt, or water splashes. Its robust design ensures longevity and maintenance-free operation in demanding environments.

    With an operating voltage range from 12V to 30V DC, the Tamagawa TS5214N500 SmartSyn Resolver is versatile and can be integrated into a wide variety of industrial control systems. It supports a load capacity up to 1A, ensuring compatibility with various control circuits.

    The output is provided in a 4-20mA analog current format, which is widely accepted in industrial control systems. This allows for seamless integration with existing control panels and devices, simplifying installation and enhancing system efficiency.
