Maximum Sampling Rate:1 GS/s
Maximum Channel Count:2
Maximum Input Range:±10 V
Bandwidth:100 MHz
Memory Depth:5 Mpts/ch
Trigger Modes:Edge, Pulse, Video, Serial, Logic, Bus, External
Operating Temperature:-10°C to 50°C
Dimensions (WxDxH):292 x 375 x 135 mm
Weight:3.6 kg
Power Supply:AC 100-240 V, 50/60 Hz
The Tektronix TBS1152B is a cutting-edge digital storage oscilloscope designed to meet the demanding needs of modern electronics professionals. Its robust design and advanced features make it an indispensable tool in the lab, factory floor, or classroom.
Featuring a maximum sampling rate of 1 GS/s, this oscilloscope ensures precise and fast signal capture, crucial for analyzing complex waveforms. With its dual-channel capacity, it provides flexibility for a wide range of test scenarios, enhancing efficiency in troubleshooting and validation processes.
Equipped with a broad input range of ±10 V, the TBS1152B can handle a variety of signals without limitation, making it suitable for diverse applications from low-level circuits to high-voltage systems. The built-in 100 MHz bandwidth allows for detailed examination of signals within a critical frequency range.
The device comes with an impressive memory depth of 5 Mpts/channel, which significantly increases the scope’s ability to store and analyze data, enabling comprehensive signal analysis over extended periods. Enhanced trigger modes including Edge, Pulse, Video, Serial, Logic, Bus, and External offer versatile triggering options for various signal conditions.
Operated within a temperature range of -10°C to 50°C, the TBS1152B is designed for durability and reliability in different environmental conditions. It boasts compact dimensions of 292 x 375 x 135 mm and weighs just 3.6 kg, ensuring easy portability and setup in any workspace. The AC power supply makes it adaptable to various electrical environments, further enhancing its usability.
