Operating Range:0 to 100 PSI
Accuracy:+/- 1% of full scale
Switching Points:Adjustable
Power Supply:12 to 24V DC
Contact Rating:10A at 250V AC or 16A at 24V DC
Relay Type:SPST
Enclosure Type:IP65
Material:Stainless Steel
Temperature Range:-40°F to 185°F
The United Electric H100-171 Pressure Switch – Diaphragm Module is engineered to deliver high-performance pressure monitoring in harsh industrial environments. Its robust stainless steel construction ensures durability against corrosive elements, making it suitable for various applications including oil & gas, chemical processing, and HVAC systems.
Featuring a compact design, this module integrates seamlessly into existing control systems, offering space-efficient installation options. The adjustable switching points allow for customized response to different pressure requirements, enhancing system adaptability.
With a wide operating temperature range (-40°C to +85°C), this switch operates reliably across extreme conditions, providing continuous monitoring without failure. Its bistable SPST switch mechanism ensures stable and accurate switching at the set pressure points.
The H100-171 is powered by a versatile voltage supply (DC 12V to 36V or AC 12V to 24V), ensuring compatibility with a broad spectrum of industrial power sources. The current rating of 10mA @ 24V DC supports efficient operation without overloading the circuit.
Designed for ease of use and maintenance, the United Electric H100-171 Pressure Switch – Diaphragm Module is equipped with standard panel mounting, facilitating quick installation and replacement. Its precision-engineered components ensure long-lasting performance, reducing downtime and maintenance costs.
